It is applicable to cutting of various nonmetal materials by die cutter.
Such as leather,Magnetic plastic,rubber and so on.
1.With special setting mechanism, and in conjunction with die cutter and cutting depth setting, the travel adjustment is simple and accurate.
2.The cutting head can automatically move horizontally,with excellent operating visual field and safe and reliable operation.
3.The self-lubricating bearing installed between the spindle and spindle seat requires no lubricating and makes no abrasion.
4.Higher speed of operation and greater productivity which can increase material yield.
5.The Gerson machinery has special cutting modes,can reduce consumption and save raw materials.
Model GRB(C)-25T to 500T
Max cutting force(T) From 25 Tons to 500 Tons
Distance between upper press board andworktable(mm) 50-240
Cutting area(mm) 1250×600,700,800,900,1000,1200, 1500
Motor power 1.5 to 22KW
Machine Net weight (KG) 1600 to 16500
1700 to 17500
