Flexibility Sheets Hydraulic two post press

The cutting  machine is widely applicable to cutting of various nonmetal materials by die cutter.

Flexibility Sheets Hydraulic two post press
Flexibility Sheets Hydraulic two post press

1.Double oil cylinder and precise double-crank connecting rod balancing mechanism adopted to gutantee the cutting depth at every cutting position is same.
2.Strong cutting power and stable forces.
3.Pressure control system ensure the accurate cutting.
4.Press are solid construction for durability and long service life.
5.The special specification can be customized

Model GRB-25/30/40/50 GRB-60/80/100 GRB-120/150/200 GRB-300/400/500
Maximum cutting power(KN/TONS) 25/30/40/50Tons 60/80/100Tons 120/150/200Tons 300/400/500Tons
Cutting Table (1250-2500)×(500-1500mm) (1250-2500)×(500-1500mm) (1250-2500)×(500-1500mm) (1600-2500)×(500-1500mm)
Max.Stroke(mm) 250mm 250mm 250mm 250mm
Motor Power(KW/HP) 2.2-4KW 5.5-7.5KW 11KW 22KW
Machine Size(mm) 2200×2700×1300mm 2300×2800×1300mm 2500×3100×1500mm 2500×3100×1500mm
Weight(kg) 1600kg-3300kg 4300kg-7600kg 9500kg-13000kg 15000kg-33000kg
