Automatic Swing Arm Cutting Machine for plastic Hairpin

This Swing Arm Cutting Machine machine is suitable for small die cutter on cutting wallet assembly, mobile phone sets, decorative pieces, leather accessories and other non-metallic materials.

 Automatic Swing Arm Cutting Machine for plastic Hairpin

Automatic Swing Arm Cutting Machine for plastic Hairpin

1.This cutting machine is light and flexible arm can be multi-faceted cutting material.
2.The whole machine use self-lubricating system to reduce wear and extend the service life of the machine.
3.The inertial of flying wheel is used to store energy, which saves the energy.
4.The use of time control allows for simple and convenient setting of cutter depth.
5.All products can be customized on your requirement.
Model GSB-8,GSB-10 GSB-2C/10/12/14/16/18
Maximum cutting power(KN/TONS) 78.5KN(8TONS), 98KN(10TONS) 10ton to 18 tons
Cutting Table 650×350mm 800×400mm,900×430,450mm
Swaying arm width(mm) 350mm 350mm
Max.Stroke(mm) 75mm 75mm
Motor Power(KW/HP) 0.75KW/1HP 0.75KW/1.5HP
Machine Dumensions(mm) 600×800×1500mm 900×900×1400mm
Packing Size(mm) 1050×1050×1500mm 1350×1200×1550mm
Net Weight(No oil)(Kg) 580kg 750-910kg
Gross Weight(Kg) 650kg 800-950kg
